Rectifier Diode Voltage Drop. first, make sure you understand diode voltage drop (if not google it). power diodes can be connected together to form a full wave rectifier that convert ac voltage into pulsating dc voltage for use. the current flow is through two diodes in series for both polarities. the peak voltage of just over nine volts versus the applied ten volts is largely due to the voltage drop across the rectifying diode. even a tiny load of.1% of capacity will drop the voltage by the amount the diodes dropped. Forward voltage for a diode varies. So subtract.7 volts or 1.4 volts from the expected peak, and the. Thus, two diode drops of the source voltage are lost (0.7·2=1.4 v for si) in the diodes.
