Duct Fittings Area Calculation In Revit. Open the project in which you wish. It can be done with dynamo script. ((2 * (height + width)) *. You can add a mass parameter as project parameter and assign it to duct fittings and then put in the mass value for each type. One for the rectangular ducts and one for the round ducts. I did the draft of a script that will take take elements from the ventilation with selection, take their surfaces and calculate surface area (select model. Some of the duct fittings have surface areas calculated, some dont. Calculate duct fitting area and write to parameter for schedulability. This process describes how to create a shared parameter to display the cross sectional area of a parametric duct fitting. I'd like to have all the fittings report an area so i can schedule total sheet. Duct fitting quantities in area parameter is normally not possible with revit alone. You could simplify the calculation by just calculating the length of the fitting centreline(s) (using angle and centre radius, for.

Some of the duct fittings have surface areas calculated, some dont. Duct fitting quantities in area parameter is normally not possible with revit alone. Calculate duct fitting area and write to parameter for schedulability. ((2 * (height + width)) *. One for the rectangular ducts and one for the round ducts. This process describes how to create a shared parameter to display the cross sectional area of a parametric duct fitting. It can be done with dynamo script. Open the project in which you wish. You can add a mass parameter as project parameter and assign it to duct fittings and then put in the mass value for each type. I'd like to have all the fittings report an area so i can schedule total sheet.
