What Is Open Circuit Resistance. The resistance in an open circuit is very high (infinite), while a short circuit has very low resistance (zero). From understanding the basics to exploring open circuit resistance, learn about the differences between open circuits and short circuits. An open circuit is defined by the absence of a complete path for current to flow, which theoretically results in infinite resistance. High or infinite resistance indicates an open circuit, while very low or zero resistance indicates a short circuit. An open circuit has infinite. The voltage drop across the open circuit terminal is equal to the voltage source. Across the short circuit terminal, the voltage drop is zero since the resistance is zero. As for the infinity symbol, the point is to illustrate that the particular. So the resistance simply resolves to the internal series resistance of the source as you have conclused. Each end of the open conducting path becomes an extension of the voltage source terminals and the voltage felt across the open is equal to the applied voltage (va).
