Oscilloscope Knobs. Turning the horizontal position knob lets you adjust where the waveform starts and stops on the screen and allows you to line it up. Try fiddling with the horizontal and vertical system knobs to maneuver the waveform around the screen. Rotating the scale knobs clockwise will “zoom into” your waveform, and counter. In this lecture, i’ll talk about the basic controls that you’ll find on any oscilloscope. This is useful for measuring such things as clock frequencies, duty cycles. Rotate the knob clockwise, and the wave will move down,. The position knob controls the vertical offset of the waveform on the screen. An oscilloscope is a tool that measures electrical signals as they change over time and represents the result as a graph. I will also show you a few examples of how these controls work on my. An oscilloscope's primary function is to provide a graph of a signal's voltage over time.
