Ac Solenoid Coil Resistance. To diagnose the solenoid, use a multimeter to test the solenoid for its resistance and voltage. The resistance of a dc coil is simply the ratio of the applied dc voltage to the dc current at room temperature (~20degc or 25degc). To determine the resistance of an ac coil of this type, one can connect a dc voltage source (~12vdc or 24vdc) and a dmm to. The impedance of an ac coil is simply the ratio of the applied ac voltage to the ac current at room temperature. For an ac sine wave impedance is calculated as r + j*2*pi*f*l, where r is the coil resistance, l is its inductance, f is the ac frequency, and j is a. A solenoid coil with a resistance of 10 ohms at 25 °c will have its resistance increase to approximately 13.9 ohms at 125 °c. The power through the coil sets the max current you want to run. There is a difference between the initial current to drive the solenoid to its new position and the current to hold it there. If there isn't a click, the solenoid coil is bad, and the solenoid needs to be changed. This 39% increase in resistance over a 100 °c rise in.
