How To Measure Centerline Radius. The distance between this meeting point and the center of your pipe bend will give you your clr. The centerline radius (clr) of a bend corresponds to the measurement from the center of the bending die to the axis (or centerline) of the tube or pipe being bent. For example, a 3 od 90° bend with a 1.5d clr will have a centerline radius of 4.5 (3 * 1.5 = 4.5). Why should you know your clr? How to calculate centerline radius to calculate clr, measure from the center of the bend to where the degrees of bend lines meet. The centerline radius (clr) is the distance from the center of the bending die to the centerline (axis) of the tube. It is possible to have a tighter bend radius, even as low as 1d. In fact, taking this measurement from the center of any point along the bend will give you the same value. To figure out the inside radius and outside radius, subtract and add half the outside diameter to the centerline radius. After you’ve selected the appropriate die for bending your pipe, based on the pipe’s outside diameter and wall thickness, you should be able to find the radius of the bend. The d multiplier figure, or in this case 1.5d, is referring to a bend that has a centerline radius that is 1.5 times the outside diameter of the material.

For example, a 3 od 90° bend with a 1.5d clr will have a centerline radius of 4.5 (3 * 1.5 = 4.5). In fact, taking this measurement from the center of any point along the bend will give you the same value. The centerline radius (clr) is the distance from the center of the bending die to the centerline (axis) of the tube. After you’ve selected the appropriate die for bending your pipe, based on the pipe’s outside diameter and wall thickness, you should be able to find the radius of the bend. Why should you know your clr? To figure out the inside radius and outside radius, subtract and add half the outside diameter to the centerline radius. How to calculate centerline radius to calculate clr, measure from the center of the bend to where the degrees of bend lines meet. The d multiplier figure, or in this case 1.5d, is referring to a bend that has a centerline radius that is 1.5 times the outside diameter of the material. The centerline radius (clr) of a bend corresponds to the measurement from the center of the bending die to the axis (or centerline) of the tube or pipe being bent. The distance between this meeting point and the center of your pipe bend will give you your clr.
