Which Key Is Used For Tapered Shaft Fitting. Like parallel keys, this sunk key type doesn’t have a uniform height, instead, they are tapered at the upper surface in the ratio of 1:100. Gib keys, or gib head keys, are tapered and notched machine keys that are used on power transmission keyed shafts to hold pulleys and. So they are called tapered keys. A common device for attaching pulleys to motors, gearboxes, and shafts is a keyed tapered bushing, which is typically made of gray iron, steel, ductile iron, or sintered steel. The taper on these keys is 0.125 in./ft, which is enough to wedge the key against the keyslot and keyway to prevent loosening. The key's head lessens the impacts of a hammering. Taper keys are usually top fitting, but may also be side fitting. Each has different characteristics and load. Four main shaft keys are available: Sunk key, saddle key, tangent key, and round key. These tapered, notched machine keys are used in keyed shafts for power transmission to securely fasten the gears and pulleys to the shaft.
