Egr Valve Diaphragm. Hooking up a vacuum pump lets you test this operation and eliminate other. Vacuum operated egr valves use a vacuum solenoid to vary the vacuum to the diaphragm and, in turn, open and close the egr. Exhaust gas flows through the valve and most of the time it is diverted through the cooler where the gas is cooled by the engine coolant. The egr valve is available in different versions: A vacuum operated egr valve uses a diaphragm to regulate the flow of exhaust gas. Vacuum is generated in the intake manifold by the downward movement of the piston during the combustion process. Early versions of pneumatic egr valve does not use electrical energy to move the actual valve, but a shaft connected to a diaphragm in vacuum. Some valves also include a feedback sensor to inform the ecu of the. If the vacuum diaphragm inside the egr. A diaphragm inside the valve is pulled when a vacuum is created, pulling on the spring and opening the valve. Pneumatic egr valves have a vacuum controlled diaphragm. If the egr valve opens and the vacuum holds for more than a minute, the egr valve works. These valves can enable a higher flow rate that is required by newer diesel applications.
