Usb Cable Shield To Ground. This allows any noise injected into the. The shield only needs to be connected on one side. In most applications, the usb shield should not be connected to ground (gnd). If the device is plugged in, the cable/shield ground is connected to the chassis ground of your computer and is as grounded as. You should tie the shield of the cable, to your enclosure, and if needed (as in the case of coax), you can tie the ground of your circuit to this same point. Connect the shield directly to ground plane. If the usb cable shield is connected directly to the gnd plane then the usb cable will act as an antenna, showing up on the spectrum analyzer with various probes. Since it's powered by the usb and not a separate power supply, some capacitor from your signal ground to the shield is probably the best choice. If you want to shield interference effect of alternating magnetic fields, the shield must be connected to ground on both ends of. Most manufacturers recommend connecting the usb connector case (which is connected to the.
