Heat Dissipation Calculation For Busbar. The type of enclosure housing the busbar affects its heat dissipation, influencing the allowable current rating. Knowing the mass of the bar and the energy produced by the short circuit current, the temperature rise can be calculated: Bar current, the power dissipation can be as high as several watts. I want to calculate heat dissipation for busbars which is to be used in a electrical enclosure. Q is the amount of heat added to the bar (joule) s is the specific heat of the bar material (j/kg/k) m is the mass of the bar (kg) tr is the temperature rise. The power dissipation is based on an rms current of sqrt(600x600x30 + 100x100x3000 + 0 x 3000)/sqrt(30 + 3000 + 3000) = 82.25 amps. Heat dissipation from the busbar by convection is different for horizontal and vertical surfaces, as shown in figure 2 and the equation. Heat transfer of the heated busbars in the switchgear can take place in three ways: An alternative approach is to use two drv425 devices connected in a differential configuration and mounted on opposite sides of a. By conductivity, convection, and radiation. The amount of energy dissipated in the bar is:
