How To Make External Threads In Creo 4. If you really want physical screw. Normally, you don't model the threads explicitly, just use a cosmetic thread feature. Click model > engineering > cosmetic thread. This vedio explains how to draw a bolt with external thread in simple manner ptc creo sweep. For a threaded connector, select two aligning surfaces. For bolt and nut, select opposing surfaces. Indicate whether you want the system to use a threaded screw or a bolt and nut. Just click tools > intelligent fastener > screw and then click a datum point, an axis, or a hole on your model where you want to add the connector. Is there any easy way to create the npt external thread something similar to internal thread just by selecting the hole location?. When you create the cosmetic thread in the properties tab, make sure that in the form cell say iso or the standard you use. Click standard thread to use standard series and diameter.
