Amplifier P1Db Meaning at Tyler Sutton blog

Amplifier P1Db Meaning. P1db or 1db compression point is the part of the curve where, 2db change in the input power fed to the amplifier(rf circuit) results into 1 db change in the output power. Calculating the cascaded values for 1 db compression point (p1db) for the system budget requires use of ratios for gain and power levels for p1db (do not use db and dbm values, respectively). The compression point is a metric describing an aspect of electronic amplifiers. Also known as p1db, this point is defined as the output power level that causes the gain of the amplifier to compress by 1db from the ideal. There are two key measurements in determining power amplifier quality, efficiency, and linearity: 1 db compression point defines the output level at which the amplifier's gain is 1 db less than the small signal gain, or is compressed by 1 db (p1db).
