Sensor Cable Shield Grounding. A good practice is to. If a cable shield is present, it should be tied to ground at the sensor (figure 2). There are two types of shielding typically used for. In this video we will discuss best practices for grounding and cable shielding for linear position sensors, electromechanical devices that are. A shield will reflect some energy, conduct some energy to ground, and pass some energy. Any electrical field on the sensor shield will flow down the shield to the agnd and be shunted away from your. • the sensor’s body or the shield of the cable should be tied to the chassis ground if it is floating or not connected to the ground internally. A shield should be at the same potential as the thing it is shielding. The shield should have direct connection on exactly one end (the other end either unconnected or connected through a small ceramic capacitor). Make the shield connection to ground as close as possible to the sensor connection to ground to avoid a difference. You could use a 1m resistor and 0.1uf capacitor in parallel to connect the shield ground and board ground together. Our board designs at my work do this.

In this video we will discuss best practices for grounding and cable shielding for linear position sensors, electromechanical devices that are. • the sensor’s body or the shield of the cable should be tied to the chassis ground if it is floating or not connected to the ground internally. The shield should have direct connection on exactly one end (the other end either unconnected or connected through a small ceramic capacitor). Make the shield connection to ground as close as possible to the sensor connection to ground to avoid a difference. You could use a 1m resistor and 0.1uf capacitor in parallel to connect the shield ground and board ground together. Any electrical field on the sensor shield will flow down the shield to the agnd and be shunted away from your. If a cable shield is present, it should be tied to ground at the sensor (figure 2). A shield will reflect some energy, conduct some energy to ground, and pass some energy. A good practice is to. Our board designs at my work do this.
