Are Pipe Dimensions Id Or Od. The “outside diameter” (od) of a pipe is a critical dimension that refers to the total outer diameter of the pipe. For example, an nps 2” pipe has an od of 2.375” while an nps 6” pipe has an od of 6.625”, and an nps 12” pipe has an od of 12.75”. Nominal pipe size and schedule collectively sets the pipe outside diameter (od) and the wall thickness (and hence the internal diameter (id) is automatically fixed). 37 rows pipe size is specified by two designations: The pipe id equals the pipe nominal bore or nominal diameter minus the wall thickness twice. A nominal pipe size (nps) for diameter based on inches, and a schedule. 175 rows use our ansi pipe schedule chart to determine the nominal pipe size, wall thickness, weight and schedule designations of carbon and stainless steel pipes. For the purpose of standardization, the american national standards institute. It is a direct measurement from one outside edge to the opposite outside. Before we head into the details of their standardization, it is important to identify their primary geometrical features and what dimensions.
