Stripline Impedance Equation. Use the following equation to calculate the impedance of a stripline trace layout. Learn how to design controlled impedance traces on pcbs using microstrip and stripline geometries. Compute the characteristic impedance of a stripline using its width, height, thickness and dielectric constant. Using typical values of w= 9 mil, h= 24 mil, t =. The characteristic impedance of a stripline is [25, 26] \[\label{eq:1}z_{0}=\left[\frac{30\pi}{\sqrt{\varepsilon_{r}}}\right]\frac{(1. A stripline is a central. For wide striplines, the above equation reduces to the following equation in terms of a fringing capacitance factor: Take note that this assumes that the distance between the conductor and the planes is not the same for both reference planes; Under specific (not mutually exclusive) approximations, the following equations define the impedance of a stripline: Stripline impedance equation for narrow strips. Stripline impedance equation for wide strips Find equations, examples, and guidelines for.
