Servo Change Duty Cycle. With a 1.5 ms pulse,. “duty cycle” is the width of positive pulse (square wave) and a deciding factor for servo’s angular position. A duty cycle is the percentage on time. A typical servo motor expects to be updated every 20 ms with a pulse between 1 ms and 2 ms, or in other words, between a 5 and 10% duty cycle on a 50 hz waveform. Duty_cycle = int (pulse_ms / (period_ms. Typically, a servo motor anticipates an update every 20 ms with a. A frequency or period is specific to controlling a particular servo. I just got it working by creating a timer1 interrupt on ctc mode with a frequency of 100khz and counting the necessary time to get. For example, if you have a servo with 180° turn, then 90° is the. 100% will be a 20000 µs pulse, way outside the range accepted by a servo. Deg_to_duty is a function that takes in a degree number as inputs and converts it into duty cycle, with respect to the max_duty and min_duty, this is much like how you. Period_ms = 1.0 / frequency * 1000.0.
