Function Of Ale Pin In 8085. Based on the pin combination of io/m and s0, s1, the data bus status is decided. Ale (address enable latch) is the control signal which is nothing but a positive going pulse generated when a new operation is. The data bus moves into an active state when ale = 1. So for the first machine cycle, you can access the address lines. The address bus will be enabled during the 1st clock cycle as the ale pin goes high i.e. The 74ls373 ic is used to hold on to these 8 bits. That is the ale pin. The ale (address latch enable) pin in the 8085 microprocessor is used to indicate when the multiplexed address/data bus contains an address. The 8085 has another pin, which helps in demultiplexing these 8 pins. It goes high during the first clock cycle to latch the address, and then goes low to allow the bus to be used for data transfer. It is the 30th pin of 8085 which is used to enable or disable the address bus. These are then latched to an external latch. So at the second machine cycle, the 8 address bits are latched and saved at the.
