Single Led Voltage. In our simple led circuit consisting of a single led, we have used a 5mm white led and a power supply of 12v. If you’re wiring a single led, then look up its forward voltage requirement and pick a battery configuration that exactly matches or. Most common led’s require a forward operating voltage of between approximately 1.2 to 3.6 volts with a forward current rating of about 10 to 30 ma, with 12 to 20 ma being the most common. The typical forward voltage of leds are 1.8v (red), 2.0v (yellow), 2.2v (green) and about 3v to 3.5v for blue. Too much voltage is bad and can burn out the led instantaneously. As per the datasheet of the 5mm white led, the forward voltage of the led is 3.6v and the forward current of the led is 30ma. The simplest way to operate an led is to apply a voltage source across it with a resistor in series. Sometimes if you give them too little voltage they wont light at all, other times they will just shine dimly with low voltage. This means, that you can run all 3 red leds without any resistor, if. Leds require sufficient voltage to light them.
