Loading Effect For An Ammeter. Any ammeter connected in a series circuit will introduce resistance to the series combination that will affect the current and voltages of the. Here is an extreme example of an ammeter’s affect upon a circuit: To measure current in a circuit, the ammeter must be placed in series with the current in question. This deviation of current from actual value is known as the loading effect of the ammeter. Meters used to measure voltage or current have an internal resistance. With the ammeter disconnected from this circuit, the current through the 3 ω resistor would be 666.7. Using current divider, the current flowing across both resistors can be calculated to be 6.67 a and 3.34 a. Ideally the piece of equipment will have a negligible. Thus the loading effect of the ammeter when connected in series with the circuit component whose current is to be measured is greatly reduced. Since the meter must be connected to the circuit to make a. Consider a 10 a current source powering two resistors of 5 and 10 ohms. The loading effect is to what degree a measurement device impacts the electrical properties of the circuit under test (ie. As in the case of the voltmeter, the insertion of the ammeter into our circuit may also disturb the.

The loading effect is to what degree a measurement device impacts the electrical properties of the circuit under test (ie. Thus the loading effect of the ammeter when connected in series with the circuit component whose current is to be measured is greatly reduced. With the ammeter disconnected from this circuit, the current through the 3 ω resistor would be 666.7. To measure current in a circuit, the ammeter must be placed in series with the current in question. Using current divider, the current flowing across both resistors can be calculated to be 6.67 a and 3.34 a. Here is an extreme example of an ammeter’s affect upon a circuit: This deviation of current from actual value is known as the loading effect of the ammeter. Consider a 10 a current source powering two resistors of 5 and 10 ohms. As in the case of the voltmeter, the insertion of the ammeter into our circuit may also disturb the. Meters used to measure voltage or current have an internal resistance.
