Timing Marks Lined Up . There's a dowel pin on the cam and the crank has a keyway. On most modern v8 engines (made after 1950), the factory will place a single line or hash mark on the harmonic balancer that. The crank mark should be aligned at tdc on the timing cover, and the cam marks should align on the timing cover. All you need to worry about is getting the two dots to align. If you have the timing cover off, the easiest way to tell if you have it at tdc on #1 cylinder for the compression stroke is to align the timing marks on the timing chain. If the dots are lined up you can't screw it up. When rotating the crankshaft and turning the engine over, the camshafts will realign after the crankshaft has turned twice. Never remove a timing belt without first marking the old one with a white sharpie at the marks to ensure you get the new one lined up properly.
