How To Use A Countersink Gage. Countersinks can be measured by many different gauges. The hand held gages quickly determine the top diameter of tapered or. Starrett countersink gages are offered in three different angles so that the gage sets on the angular side of the countersink, as. A countersink gage is most popular in the aerospace industry and has a solid cone (under normal circumstances) ground to an exact angle that measures a. The easiest tool to use, assuming the tolerances aren’t too tight, is a pocket. The dial indicating chamfer diameter gage has been a staple inspection tool in many machine shops for decades now. This is the simplest case and. I will be working two examples: How to measure a countersink. Most chamfer diameter gages give the user a way of quickly verifying the calibration setting without using a ring gage or other setting standard. The countersink gauge gives the tool datum at the theoretical tip point so the countersink diameter is always double the depth for 90 degree countersinks and spot drills.
