Sheet Metal Thickness In Inventor. If you design small objects, this material is often thin. This tutorial will show you how to create a thick or thin metal plate using the inventor sheet metal. Create a sheet metal part using the sheet metal template. The template uses your settings for material thickness, bend radius, and corner. You should define your sheet metal rule as.0747 inch thickness, but there is no way that you should dimension it in a drawing that. To set the parameters, click sheet metal > setup > sheet metal defaults on the ribbon; A sheet metal part is often thought of as a part fabricated from a sheet of uniformly thick material. Inventor can create specific custom iproperties and classify by them. The sheet metal defaults dialog appears. When you use the face command in sheet metal how and where is the thickness determined and changed? Go to the sheet metal tab, under setup, pick sheet metal defaults, uncheck use thickness from rule, type in the new value.
