Inertia Ratio For Servo Motor. It is an important parameter. When choosing and calculating an inertia ratio, find the smallest. Inertia is defined an object’s. Inertia, or more specifically, inertia ratio, is one of the most important factors in sizing a servo system. Inertia ratio is defined as the ratio of the load inertia to the rotor inertia in a servo motor and gearbox system. System inertia ratios should be designed for a max of 10:1 but are typically 5:1 for ideal performance. The rotor inertia of a servo motor is a very important parameter in the design and use of motors, which is directly related to the control performance and responsiveness of the motor. Assuming a gear reduction ratio of 1:r, the load inertia reflected on the servo motor shaft is 15625/r 2. According to the principle that the load inertia should be less than three times the rotor inertia j m of the motor, J l = inertia of load reflected to motor j m = inertia of motor. The ratio of the load inertia to the motor inertia is one of the most important aspects of servo motor sizing.
