Rod End Ball Joint Definition. When selecting a rod end or spherical bearing for your application it is crucial to understand the different types of liners and materials. A rod end is a joint that allows for some rotational freedom about all three axes while maintaining a fixed point of contact between two parts. Rod ends, also known as heim joints or rose joints, are a common component that we rely on when fabricating suspension arms in particular,. Rod end bearings provide articulation and rotational movement in mechanical systems and are ideal in robotic and automotive linkage applications. The most common type of rod end you’ll find in an fsae paddock has a hardened alloy steel ball and race (both of which are usually chrome plated) with an incredibly thin ptfe liner between the two. Rod ends are used to join the ends of steering links, control rods, and other mechanically Rod ends are constructed with a. A ball joint linkage, with its mounting axes nominally perpendicular to each other is very similar to a rod end. They differ in that the inner spherical surface does not have a hole through its.
