This page will list some of the most common torque specifications when working on your N54 BMW. Oil Filter Housing to Cylinder Head (3 Bolts) 22Nm or 16.22Ft lb Oil Pressure Sensor to Oil Filter Housing 20nm + 16° or 14.75ft lb + 16 Degrees Oil Cooler to Oil Filter Housing (3 Bolts) 19Nm or. Tightening Torques Cylinder Head and Cover 2AZ Cylinder head bolts Replace, wash and oil cylinder head bolts.

For repair work, only use screws with Torx head M20 M10 torque. ALL Torque Specs for N54 11:13 PMALL Torque Specs for N54. Torque angle 90 ° 4AZ Bedplate Aluminium screws/bolts are marked with blue paint.

N54 M10x41 Replace screws Thread repairs exclusively with Al Helicoil. Jointing torque and angle of rotation must be observed without fail. Jointing torque 15 Nm Torque angle 90 ° 5AZ Oil spray nozzles to engine block N54 Hollow bolt 12 Nm 6AZ Screw plug, water.

Complete BMW 335i 2005-2011 3.0L Engine bolt torque specifications and tightening sequences. Includes factory torque values for critical fasteners: cylinder head bolts, main bearing cap bolts, connecting rod bolts, flywheel bolts, timing cover bolts, and all engine assembly fasteners. Essential data for proper assembly, including torque.

Hello all, I put my sons new head on last night and followed procedures in the "Bently". I torqued to 22ft. Yes All bolts in proper sequence to 50Nm Then all bolts in proper sequence to 120 degrees then all bolts in proper sequence another 120 degrees There are two 120 degree pulls.

An electronic torque wrench that reads angle measurements AND keeps track so that you can ratchet two 60 degree pulls to equal 120 degrees, is a big help in this job. These are torque to yield head bolts, and torqueing. 90 ° 3.

Angle of rotation 45 ° 2AZ Cylinder head bolts N54 M9x95 M9x125 Replace screws Jointing torque 30 Nm 1st angle of rotation 90 ° 2. Angle of rotation omitted 3. Angle of rotation 45 ° 3AZ Cylinder head bolts N54 M9x30 M9x70 22 Nm 4AZ Cylinder head cover to cylinder head N54 M6 8.5 Nm 5AZ Metal bracket to cylinder head N54 M6x16 8 Nm.

BMW Wheel Tightening Torque Specifications N54 Torque Specs Cheat Sheet M57 Torque Specifications Cheat Sheet N54 N54 Spark Plugs N54 Ignition Coils Catted and Catless Downpipes. 1- Front Seal Installation 2- Crankshaft Hub Torque 3- Oil Pan Installation 4- Cylinder Head Installation / Torque Head Bolts 5.
