Class BaseObject

source code


Nested Classes
  __metaclass__
Give each object a unique ID.
Instance Methods

__init__(self, type_name=None, offset=0, vm=None, profile=None, parent=None, name='', context=None, session=None, **kwargs)
Constructor for Base object.
source code

GetData(self)
Returns the raw data of this object.
source code

proxied(self) source code

write(self, value)
Function for writing the object back to disk
source code

__nonzero__(self)
This method is called when we test the truth value of an Object.
source code

__eq__(self, other) source code

__hash__(self)
hash(x)
source code

m(self, memname) source code

is_valid(self) source code

deref(self, vm=None)
An alias for dereference - less to type.
source code

dereference(self, vm=None) source code

reference(self)
Produces a pointer to this object.
source code

cast(self, type_name=None, vm=None, **kwargs) source code

v(self, vm=None)
Do the actual reading and decoding of this member
source code

__str__(self)
str(x)
source code

__unicode__(self) source code

__repr__(self)
repr(x)
source code

__dir__(self)
Hide any members with _.
source code

__format__(self, formatspec)
default object formatter
source code

Inherited from object: __delattr__, __getattribute__, __new__, __reduce__, __reduce_ex__, __setattr__, __sizeof__, __subclasshook__

Class Methods

getproperties(cls)
Return all members that are intended to represent some data.
source code
Class Variables
  obj_parent = <No parent>
  obj_name = <No name>
  obj_producers = None
hash(x)
Properties
  obj_size
  obj_end
  parents
Returns all the parents of this object.
  indices
Returns (usually 1) representation(s) of self usable as dict keys.

Inherited from object: __class__

Method Details

__init__(self, type_name=None, offset=0, vm=None, profile=None, parent=None, name='', context=None, session=None, **kwargs)
(Constructor)

source code
Constructor for Base object.

Args:
  type_name: The name of the type of this object. This different
     from the class name, since the same class may implement many types
     (e.g. Struct implements every instance in the vtype definition).

  offset: The offset within the address space to this object exists.

  vm: The address space this object uses to read itself from.

  profile: The profile this object may use to dereference other
   types.

  parent: The object which created this object.

  name: The name of this object.

  context: An opaque dict which is passed to all objects created from
    this object. This dict may contain context specific information
    which each derived instance can use.

  kwargs: Arbitrary args this object may accept - these can be passed in
     the vtype language definition.

Overrides: object.__init__

__nonzero__(self)
(Boolean test operator)

source code
This method is called when we test the truth value of an Object.

In rekall we consider an object to have True truth value only when it is
a valid object. Its possible for example to have a Pointer object which
is not valid - this will have a truth value of False.

You should be testing for validity like this:
if X:
   # object is valid

Do not test for validity like this:

if int(X) == 0:

or

if X is None:
  .....

the later form is not going to work when X is a NoneObject.

__hash__(self)
(Hashing function)

source code

hash(x)

Overrides: object.__hash__
(inherited documentation)

reference(self)

source code

Produces a pointer to this object.

This is the same as the C & operator and is the opposite of deref().

v(self, vm=None)

source code

Do the actual reading and decoding of this member

When vm is specified, we are asked to evaluate this object is another address space than the one it was created on. Derived classes should allow for this.

__str__(self)
(Informal representation operator)

source code

str(x)

Overrides: object.__str__
(inherited documentation)

__repr__(self)
(Representation operator)

source code

repr(x)

Overrides: object.__repr__
(inherited documentation)

__format__(self, formatspec)

source code

default object formatter

Overrides: object.__format__
(inherited documentation)

Property Details

obj_size

Get Method:
unreachable.obj_size(self)

obj_end

Get Method:
unreachable.obj_end(self)

parents

Returns all the parents of this object.

Get Method:
unreachable.parents(self) - Returns all the parents of this object.

indices

Returns (usually 1) representation(s) of self usable as dict keys.

Using full base objects for indexing can be slow, especially with Structs. This method returns a representation of the object that is a suitable key - either the value of a primitive type, or the memory address of the more complex ones.

Get Method:
unreachable.indices(self) - Returns (usually 1) representation(s) of self usable as dict keys.
