Package rekall :: Package ui :: Module renderer :: Class BaseRenderer

Class BaseRenderer

All renderers inherit from this.

This class defines the only public interface for the rendering system. This is the API which should be used by Rekall plugins to render the output. Derived classes can add additional methods, but these should not be directly used by the plugins - otherwise plugins will fail when being rendered with different renderer implementations.

Nested Classes
	__metaclass__ Automatic Plugin Registration through metaclasses.
	table_class Renderers contain tables.
	top_level_class All renderers inherit from this.

Instance Methods

__init__(self, session=None)
x.__init__(...) initializes x; see help(type(x)) for signature

source code

__enter__(self)

source code

__exit__(self, exc_type, exc_value, trace)

source code

start(self, plugin_name=None, kwargs=None)
The method is called when new output is required.

source code

end(self)
Tells the renderer that we finished using it for a while.

source code

write(self, data)
Renderer should write some data.

source code

section(self, name=None, width=50)
Start a new section.

source code

format(self, formatstring, *data)
Write formatted data.

source code

flush(self)
Renderer should flush data.

source code

table_header(self, columns=None, **options)
Table header renders the title row of a table.

source code

table_row(self, *row, **kwargs)
Outputs a single row of a table.

source code

report_error(self, message)
Render the error in an appropriate way.

source code

RenderProgress(self, *_, **kwargs)
Will be called to render a progress message to the user.

source code

open(self, directory=None, filename=None, mode='rb')
Opens a file for writing or reading. source code

get_object_renderer(self, target=None, type=None, target_renderer=None, **options)

source code

Log(self, record)
Logs a log message.

source code

Inherited from object: __delattr__, __format__, __getattribute__, __hash__, __new__, __reduce__, __reduce_ex__, __repr__, __setattr__, __sizeof__, __str__, __subclasshook__

Class Methods

ImplementationByClass(self, name)

source code

ImplementationByName(self, name)

source code

Class Variables
	name = `None` hash(x)
	last_spin_time = `0`
	last_gc_time = `0`
	progress_interval = `0.2`
	table = `None` hash(x)
	classes = `{'BaseRenderer': <class 'rekall.ui.renderer.BaseRend...`
	classes_by_name = `{None: [<class 'rekall.ui.renderer.BaseRende...`
	plugin_feature = `'BaseRenderer'`

Properties
Inherited from `object`: `__class__`

Method Details

init(self, session=None)
(Constructor)

source code

x.__init__(...) initializes x; see help(type(x)) for signature

Overrides: object.__init__: (inherited documentation)

start(self, plugin_name=None, kwargs=None)

source code

The method is called when new output is required.

Metadata about the running plugin is provided so the renderer may log it
if desired.

Args:
   plugin_name: The name of the plugin which is running.
   kwargs: The args for this plugin.

section(self, name=None, width=50)

source code

Start a new section.

Sections are used to separate distinct entries (e.g. reports of different files).

format(self, formatstring, *data)

source code

Write formatted data.

For renderers that need access to the raw data (e.g. to check for NoneObjects), it is preferred to call this method directly rather than to format the string in the plugin itself.

By default we just call the format string directly.

table_header(self, columns=None, **options)

source code

Table header renders the title row of a table.

This also stores the header types to ensure everything is formatted appropriately. It must be a list of specs rather than a dict for ordering purposes.

Log(self, record)

source code

Logs a log message. Implement if you want to handle logging.

Class Variable Details

classes

Value:

{'BaseRenderer': <class 'rekall.ui.renderer.BaseRenderer'>,
 'DataExportRenderer': <class 'rekall.plugins.renderers.data_export.Da
taExportRenderer'>,
 'IdentityRenderer': <class 'rekall.ui.identity.IdentityRenderer'>,
 'JsonRenderer': <class 'rekall.ui.json_renderer.JsonRenderer'>,
 'TestRenderer': <class 'rekall.ui.text.TestRenderer'>,
 'TextRenderer': <class 'rekall.ui.text.TextRenderer'>,
 'WideTextRenderer': <class 'rekall.ui.text.WideTextRenderer'>}

classes_by_name

Value:

{None: [<class 'rekall.ui.renderer.BaseRenderer'>,
        <class 'rekall.ui.identity.IdentityRenderer'>],
 'data': [<class 'rekall.plugins.renderers.data_export.DataExportRende
rer'>],
 'json': [<class 'rekall.ui.json_renderer.JsonRenderer'>],
 'test': [<class 'rekall.ui.text.TestRenderer'>],
 'text': [<class 'rekall.ui.text.TextRenderer'>],
 'wide': [<class 'rekall.ui.text.WideTextRenderer'>]}
